Pre-assemble all parts before shipping, which will save you time on site installation and costs on site construction operations.

Material: AL6005-T5, surface anodized, with high corrosion and salt resistance.

There are also corresponding piles for paddy fields with soft soil.

It can also be designed according to the small board of agricultural power generation.

Compared with the installation of other manufacturers need at least 3 people, our independent research and development of the main beam and track, only need two people to complete the installation.

The installation height is 2m~4m (from the field to the panel), and the left and right span can be up to 6m, which can use light to generate electricity without affecting the growth of crops.

The solar panel can be fixed at a certain Angle (5°~30°), leaving some gap with the side of the solar panel to meet the sunshine needs of crops and achieve land reuse.

Technical Information:

Benefits：

1.Effective use of space, power generation on the top, farming on the bottom, and getting both farming and power generation profits.

2.Securing a space where humans and farming machines can get inside.

3.Components pre-assembled in advance, it will save your labour cost and installation time.

4.Material：AL6005-T5 with surface Anodizing processing, achieving high corrosiom resistance and salt tolerance.

5.Depending on the panel installation method, the shading rate of the gantry can be adjusted to meet the required amount of sunlight for the plant.

6.Warranty:10 years warranty,25 years product service life.

Project Reference：

To meet the sunshine gap need of crops, the height from ground is usually very high.Recommending the bottom panel fixed structure because of easy construction and satefy.There is no need to climb over the panel to install. Bottom panel fixed could make sure the safety of workers and prevent the panel from cracks.

Features：

1. It able to pre-assembled in factory to reduce the labor cost and installation time on site

2. High anti-corrosion

3. Customized availble as request

 Parts Drawing：

connector schematic diagram:

全球安装案列

If you need a design and quotation for your project, please share below data with us:

Module dimension: length, width and thickness?
Tilt angle?
Panel Layout: how many solar panels in a row, how many solar panels in a column and how many solar panels in total?
Snow load on project site?
Wind load on project site?

FAQ：

Q1: what is your primary products ?

A: Solar mounting system for rooftop, ground, car parking and agriculture. Also ground screw, fence,hook,etc.

Q2:Do we offer sample?

A: Yes. We offer free sample, Welcome to check our sample.

Q3: How long is our delivery time ?

A: 1-2 days for sample, about 1-3 weeks for massive production,depends on the quantity. lf we have items in stock that could ship immediately after payment.
